CAX-BT01BM-2PS-28 2 MP metal mini bullet IP camera with a fixed lens and PoE support
Key Features Direct cloud platform integration: The built-in proprietary Agent service enables the camera to function as an independent edge device and transmit video, audio, and metadata directly to the video surveillance platform over a secure connection without requiring additional intermediary devices or equipment. 2 MP progressive scan CMOS sensor; 2 MP video stream (1920×1080) at 30 fps Fixed 2.8 mm / 3.6 mm lens 2 array IR LEDs; IR illumination range up to 30 m Power supply: PoE / DC 12 V DWDR, 3D DNR, AGC, MGC, AWB, ROI 120 dB true WDR IP67 Intelligent motion detection	Overall dimensions: 85 mm × 93 mm

CAX-BT01BM-2PS-28

2 MP metal mini bullet IP camera with a fixed lens and PoE support

Key Features

Direct cloud platform integration: The built-in proprietary Agent service enables the camera to function as an independent edge device and transmit video, audio, and metadata directly to the video surveillance platform over a secure connection without requiring additional intermediary devices or equipment.
2 MP progressive scan CMOS sensor; 2 MP video stream (1920×1080) at 30 fps
Fixed 2.8 mm / 3.6 mm lens
2 array IR LEDs; IR illumination range up to 30 m
Power supply: PoE / DC 12 V
DWDR, 3D DNR, AGC, MGC, AWB, ROI
120 dB true WDR
IP67
Intelligent motion detection

Overall dimensions: 85 mm × 93 mm

Technical Specifications CAX-BT01BM-2PS-28

Camera
SoC	SSC377 + SC231AH
Image Sensor	1/3" 2 MP progressive scan CMOS
Effective Pixels	3 MP (2304×1280) / 2 MP (1920×1080)
Minimum Illumination	0.01 lux @ F1.8 (AGC on), 0 lux with IR illumination
Shutter Speed	1/2 s to 1/50,000 s
Lens	Fixed, 2.8 mm / 3.6 mm
Day/Night	IR cut filter: auto / manual / scheduled switching
DNR	3D digital noise reduction
WDR	True WDR: 120 dB hardware WDR
Compression Standard
Video Codec	H.265+ / H.264+ / H.265 / H.264 / MJPEG
Bit Rate	main stream — 256–8000 kbps sub stream — 50–1000 kbps
Maximum Resolution	3 MP (2304×1280)
Frame Rate	30 fps at 3 MP / 2 MP / 960P / 720P
Main Stream	30 fps at 3 MP (2304×1280) 30 fps at 2 MP (1920×1080) 30 fps at 960P (1280×960) 30 fps at 720P (1280×720)
Sub Stream	30 fps at D1 (704×576) 30 fps at VGA (640×480) 30 fps at HVGA (640×360) 30 fps at CIF (352×288)
Functions	DWDR, 3D DNR, AGC, MGC, AWB, ROI, motion detection, privacy masking
Image Settings	Mirror, saturation, brightness, sharpness and contrast adjustment, exposure, DWDR, shutter, aperture, LDC, etc.
Network
Protocols	TCP/IP, UDP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP; SNMP v1/v2/v3, IPv4/v6; Bonjour; ICMP, IGMP, QoS, SSL/TLS.
Compatibility	HTTP CGI, ONVIF, WebRTC
Proprietary Protocols	Proprietary protocols for Hikvision, Dahua, Uniview, and XM Plug-and-play compatibility with the specified NVRs and CMS platforms AI functions can operate with Uniview NVRs and CMS platforms
Intelligent Detection	Intelligent motion detection
Interface
Network Interface	RJ-45 LAN port
PoE	Yes, built in
General
Color	White
Power Supply	PoE / DC 12 V
Operating Humidity	10%–90%
Operating Temperature	-40°C to +60°C
Power Consumption	Max. 6 W
Dimensions	93 mm × 85 mm
Weight	Net weight: 360 g; gross weight: 460 g
Ingress Protection	Metal housing; IP67 water resistance; suitable for indoor and outdoor installation
Accessories	Printed user manual, mounting kit
