Specification. Netland

Key features and specifications:

• Remote operation over the internet. MQTT support and RTSP video streaming allow the panel to integrate with remote systems and services, including when the device operates behind NAT.

• Compatibility with hybrid intercom infrastructure. The panel supports modern IP coordinate-matrix switches, allowing integration with existing analog intercom systems.

• Dual power options – DC and PoE. The panel supports 12–15 V DC and PoE, allowing power and data to be transmitted over a single Ethernet cable and simplifying installation.

• Support for popular contactless access technologies. The built-in reader supports EM-Marine (ID) and MIFARE (IC) cards and identifiers, simplifying integration with existing access control systems.

• BLE support and automatic door opening. The panel can be equipped with a BLE controller, enabling Bluetooth-based smartphone identification and automatic door opening when a user approaches the entrance.

• HD video with a wide viewing angle. The built-in 2 MP camera provides a 125° viewing angle for broad coverage of the area in front of the panel. H.265 support reduces video bandwidth while maintaining high image quality.

• Full-duplex voice communication. Simultaneous two-way audio provides natural conversations without requiring users to switch between speaking and listening modes.

• High-quality voice transmission and audio processing. G.711 μ-law audio at 64 Kbps, combined with built-in noise and echo cancellation, improves speech clarity in outdoor environments and areas with background noise.

• Built-in 4.3-inch color touchscreen. The panel features a 4.3-inch color TFT LCD with a resolution of 480 × 272 pixels and touch controls for convenient interaction with the device interface.

• Rugged IP65-rated outdoor enclosure. IP65 protection safeguards the equipment against dust and water jets.

• IK07 vandal-resistant enclosure. The enclosure meets the IK07 mechanical protection rating, improving the panel's resistance to mechanical impact in public and multi-unit residential buildings.

• Wide operating temperature range. The operating temperature range of −30 °C to +60 °C allows the panel to operate reliably in various climates and outdoor environments.
